JWT75-522-R 데이터시트(PDF) 1 Page - TDK Electronics |
|
|
|||||||||||||||||||||||||||||
JWT75-522-R 데이터시트(HTML) 1 Page - TDK Electronics |
|
|
1 / 2 page  AC-DC Power Supplies 1 of 1 Creation Date : February 15, 2019 (GMT) JWT75-522/R Sales Region Worldwide Series JWT Status Production Feature Option Remote ON/OFF control Option Lineup Please refer to here. Recommended EMC Filter Please refer to here. Accessories Please refer to the catalog Electrical Characteristics Input Voltage Range[AC] 85 to 265V Input Voltage Range[DC] 120 to 330V Efficiency 72% Typ. Rated Output Voltage[DC] +5V +12V -12V Output Voltage Range[DC] +5 to +5.25V Fixed Fixed Minimum Output Current 0.8A 0A 0A Maximum Output Current 8A 4A 0.5A Maximum Average Current Maximum Peak Current Total Maximum(Average) Output Power 75W Total Maximum Peak Power Cases Shape & Size Case’ｓ shape Unit Width(W) 42mm Nom. Height(H) 92mm Nom. Depth(D) 188mm Nom. Weight 600g Typ. Other Operating Temp. Range -10 to 65°C Cooling Convection cooling Safety Standard(Certified) UL60950-1 CSA C22.2 No.60950-1 EN60950-1 Safety Standard(Conformed) Den-an |
