background image
IP5328P
V1.2
Email: service@injoinic.com
4 / 27
Copyright © 2015, Injoinic Corp.
26
KEY
按键检测引脚，复用 WLED 照明功能。
27
VREG
芯片 3.1V 电压输出
28
BAT
电池供电节点
29
AGND
模拟地
30
VIN
VIN 充电电源检测引脚
31
VING
VIN 充电输入 PMOS 控制引脚
32
VBUS
VBUS 充电电源检测引脚
33
VBUSG
VBUS 充电输入 PMOS 控制引脚
34
VOUT2
VOUT2 放电负载智能检测引脚
35
VOUT2G
VOUT2 放电输出 NMOS 控制引脚
36
VOUT1G
VOUT1 放电输出 NMOS 控制引脚
37
VOUT1
VOUT1 放电负载智能检测引脚
38
DMA1
VOUT1 口手机快充智能识别 DM
39
DPA1
VOUT1 口手机快充智能识别 DP
40
DMA2
VOUT2 口手机快充智能识别 DM
41(EPAD)
GND
功率地和散热地，需要保持与 GND 良好接触
