EM8800A

TOFF section

Off Time

R_TOFF=30K ohm

6

us

R_TOFF=10K ohm

1.8

2

2.2

us

Minimum Off Time

R_TOFF=1K ohm

0.435

us

Maximum Off Time

R_TOFF=60K ohm

12

us

TOFF Short Protection Trigger Level

0.3

0.4

0.5

V

Off Time Variation vs. VCC

VCC=9.5V to 16V

2

%

Off Time Variation vs. Temperature

-20°C to 105°C

5

%

PWMD Section

PWMD ON Voltage Threshold

2.2

V

PWMD OFF Voltage Threshold

0.8

V

PWMD Pin Open Voltage

N

5

V

PWMD Pin Internal Pull High Current

2

4

6

uA

Dimming Wake-up Time

1

us

LD/SS Section

LD/SS Pin Open Voltage

5

V

LD/SS Pin Internal Pull High Current

18

20

22

uA

LD/SS Pin Voltage to Peak Current Ratio

2.85

3

3.15

V/V

FAULT Section

FAULT Internal Pull Low Current

6

10

uA

FAULT Pull high Voltage

5

V

FAULT Pull high Capability

1

2

mA

Protection Section

Maximum On Time

50

us

Over Current Trigger Level

1.45

1.5

1.6

V

Suspend mode Vcs over voltage protection

1.45

1.5

1.6

V

OCP Leading Edge Blanking Time

550

ns

Start-up Delay

80

130

160

ms

Thermal Shutdown

135

155

°C

Thermal Shutdown Hysteresis

40

°C
