 2 / 3 page
background image
General Specifications
Parameters
Conditions
Min
Typ
Max
Units
Isolation Voltage
Input To Output
Input(Output) To Case
1500
1000
Vdc
Isolation
Resistance
500Vdc
1000
MΩ
Switching
Frequency
Full load, nominal input
275
KHz
Operating
Temperature
Without Heatsink
With Heatsink
-40
-40
75
77
°C
Case Temperature
105
°C
Humidity
Non Condensing
5
95
%
Cooling
Natural Convection (20LFM)
Case material
Six-side shield case
MTBF
MIL-HDBK-217F@25℃
1200000
Hours
Weight
without heatsink
22
g
with heatsink
24.5
Dimensions
25.4X25.4X10.6
mm
96DW-R6 SERIES
YUAN DEAN SCIENTIFIC CO.,LTD
Output Specifications
Parameters
Conditions
Min
Typ
Max
Units
Voltage Tolerance
100% full load
±2
%
Short Circuit
Protection
Continuous ,Auto-Recovery
Output Power
Protection
Continuous ,Auto-Recovery
110
170
%
Over Voltage
Protection
Line Regulation
3.3Vdc
3.7
5.4
Vdc
5Vdc
5.6
7.0
12Vdc
13.5
19.6
15Vdc
18.3
22.0
24Vdc
29.1
32.5
Line Regulation
Nominal Input Voltage
±0.5
%
Load Regulation
Single
±0.5
%
Ripple & Noise
BW=DC To 20MHz
Single :
3.3V & 5V with 22uF
12V & 15V with 2*22uF
24V with 2*6.8uF
100
mVp-p
Start up time
Nominal Input Voltage
30
ms
Transient response
setting time
25% load step change
350
us
Temperature Derating Graph
@20LFM
Rev:0 2018/10/31
