Technical Data 4147
Effective April 2016
Supersedes March 2007
DR1040
Shielded power inductors
Description
•
Shielded drum core
•
Inductance range from 1.4 μH to 323 μH
•
Current range from 0.52 A to 10 A
•
10.5 mm x 10.3 mm footprint surface mount
package in a 4.0 mm height
•
Ferrite core material
•
Halogen free, lead free, RoHS compliant
Applications
•
LED/LCD backlighting
•
High definition televisions (HDTV)
•
Server and desktop power supplies
•
Portable electronics
•
Graphics cards and battery powered systems
•
Point-of-load (POL) modules
•
Printers and peripherals
Environmental Data
•
Storage temperature range (Component):
•
-40 °C to +125 °C
•
Operating temperature range: -40 °C to +125 °C
(ambient plus self-temperature rise)
•
Solder reflow temperature: J-STD-020D
compliant
Pb
HALOGEN
HF
FREE
