DR124-101-R 데이터시트(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
DR124-101-R 데이터시트(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 5 page  Technical Data 4141 Effective March 2019 Supersedes September 2017 DR124 High power density, high efficiency, low profile shielded drum core power inductors Product features • Low profile surface mount inductor • 12.5 mm x 12.5 mm x 4.5 mm shielded drum core • Inductance range from 0.47 µH to 1000 µH • Current range from 0.44 A to 24.4 A • Frequency range up to 1 MHz • Ferrite core material Applications • Notebook power • LCD panels • Desktop and servers • DVD players and portable power devices • DC-DC Converters • Buck, boost, forward, and resonant converters • Noise filtering and filter chokes Environmental Data • Storage temperature range (Component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant Pb HALOGEN HF FREE |
