1 / 6 page  Technical Data 4139 Effective April 2016 Supersedes March 2007 DR1050 Shielded power inductors Description • Shielded drum core • Inductance range from 0.7 μH to 1000 μH • Current range from 0.43 A to 13.5 A • 10.5 mm x 10.3 mm footprint surface mount package in a 5.0 mm height • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • LED/LCD backlighting • High definition televisions (HDTV) • Server and desktop power supplies • Graphics cards and battery powered systems • Point-of-load (POL) modules • Printers and peripherals • Portable electronics Environmental Data • Storage temperature range (Component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
