FP2-D100-R 데이터시트(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP2-D100-R 데이터시트(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 5 page  Technical Data 4110 Effective December 2015 Supersedes July 2014 Product description • High current carrying capacity • Dual conductors allow for low inductance and high current or high inductance and lower current • Inductance range from 0.047uH to 0.480uH • Current range 9.0 to 42 Amps • 7.2 x 6.7mm footprint surface mount package in a 3.0 or 5.0mm heights • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Servers • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) • Server and desktop • Central processing unit (CPU) • Graphics processing unit (GPU) • Application specific integrated circuit (ASIC) • High power density • Notebook regulators • Battery power systems • Graphics cards Environmental data • Storage temperature range (component): -40°C to +125°C • Operating temperature range: -40°C to +125°C (Ambient plus self temperature rise) • Solder reflow temperature: J-STD-020D compliant FP2 Low profile, high current power inductors Pb HALOGEN HF FREE |
