FP0805R1-R03-R 데이터시트(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP0805R1-R03-R 데이터시트(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 4340 Effective June 2017 Supersedes December 2008 Product features • 7.5 x 7.6 x 5mm surface mount package • Ferrite core material • High current carrying capacity, Low core losses • Controlled DCR tolerance for sensing circuits • Inductance range from 32nH to 200nH • Current range from 20 to 110 Amps • Frequency range up to 2MHz Applications • Storage temperature range (component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant FP0805 High frequency, high current power inductors Pb HALOGEN HF FREE • Multi-phase regulators • Voltage Regulator Module (VRM) • Point-of-load modules • Desktop and server VRM’s and EVRD’s • Data networking and storage systems • Graphics cards and battery power systems • DCR sensing Environmental data SMD Device |
