Technical Data

4407

Effective June 2015

FP0906

High frequency, high current power inductors

www.eaton.com/elx

Product specifications

(nH) ±10%

(nH) minimum

I

rms

3

(amps)

I

4

(amps)

I

5

(amps)

DCR (mΩ) ±5%

@ 20°C

FP0906R1-R10-R

100

72

51

94

81

0.29

451

FP0906R1-R12-R

120

86

51

79

68

0.29

451

FP0906R1-R15-R

150

108

51

65

55

0.29

451

FP0906R1-R18-R

180

129

51

55

45

0.29

451

FP0906R1-R22-R

220

155

51

44

37.5

0.29

451

FP0906R1-R28-R

280

200

51

34

29

0.29

451

FP0906R1-R30-R

300

216

51

32.5

27.5

0.29

451

1 Open Circuit Inductance (OCL) Test Parameters: 100kHz, 1.0Vrms, 0.0Adc, +25°C

2. Full Load Inductance (FLL) Test Parameters: 100kHz, 1.0Vrms, I

3. I

for AC currents. PCB layout, trace thickness and width, air-flow, and proximity of other heat

generating components will affect the temperature rise. It is recommended that the temperature

of the part not exceed 125°C under worst case operating conditions verified in the end application.

4. I

5. I

6. K-factor: Used to determine B

-3

. B

factor from table), L: (Inductance in nH), I (Peak to peak ripple current in Amps).

7. Part Number Definition: FP0906Rx-Rxx-R

FP0906 = Product code and size

Rx= DCR indicator

Rxx= Inductance value in uH, R= decimal point

-R suffix = RoHS compliant

Recommended Pad Layout

Schematic

0906Rx

Rxx

wwllyy R

1

2

4.00

2.54

10.40

2.3

±0.2

2.14

±0.2

0.3 ref

b

a

8.0

max

6.2

±0.2

1

2

Dimensions–mm

Part marking: 0906Rx (Rx=DCR indicator), Rxx=Inductance value in uH (R=decimal point),

www=date code

R=revision level

The nominal DCR is measured between point “a” and point “b”

Soldering surfaces to be coplanar within 0.1 millimeters

Do not route traces or vias underneath the inductor

Packaging–mm

Supplied in tape and reel packaging , 600 parts per 13” diameter reel

User direction of feed

1.5 dia

1.5 dia

4.0

2.0

1.75

12.0

6.5

11.5

24.00

±0.3

9.7

8.0
