Technical Data 4337

Effective April 2016

Supersedes December 2008

FP1005R

High frequency, high current power inductors

Description

•

High current carrying capacity

•

Low core loss

•

Magnetically shielded

•

Frequency range up to 2 MHz

•

Inductance range 85 nH to 220 nH

•

Current range 33 A to 90 A

•

10.2 mm x 7.0 mm footprint surface mount

package in a 4.95 mm height

•

Ferrite core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Multi-phase and Vcore regulators

•

Voltage Regulator Modules (VRMs)

•

Server and desktop

•

Central processing unit (CPU)

•

Graphics processing unit (GPU)

•

Application specific integrated circuit (ASIC)

•

High power density

•

Data networking and storage systems

•

Graphics cards and battery power systems

•

Portable electronics

•

Point-of-Load modules

Environmental Data

•

Storage temperature range (Component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature: J-STD-020D

compliant

Pb

HALOGEN

HF

FREE
