Technical Data 10476

Effective November 2015

FP1108B

High frequency, high current power inductors

Product description

•

High current carrying capacity

•

Low core loss

•

Tight tolerance DCR for sensing circuits

•

11.6 x 8.0mm footprint surface mount package

in 8.0mm height

•

Ferrite core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Servers

•

Multi-phase and Vcore regulators

•

Voltage Regulator Modules (VRMs)

•

Server and desktop

•

Central processing unit (CPU)

•

Graphics processing unit (GPU)

•

Application specific integrated circuit (ASIC)

•

High power density

•

Data centers, networking and storage systems

•

Point-of-Load modules

•

DCR Sensing circuits

Environmental data

•

Storage temperature range (Component):

-40°C to +125°C

•

Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

•

Solder reflow temperature:

J-STD-020D compliant

Pb

HALOGEN

HF

FREE
