1 / 6 page  Technical Data 10448 Effective October 2015 FP1108L1 and FP1108L2 High frequency, high current power inductors Description • High current carrying capacity • Low core loss • Ultra low DCR • Inductance range from 105nH to 150nH • Current range from 48 to 81 amps • 11.0 x 8.2mm footprint surface mount package in an 8.3mm height • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Servers • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) • Desktop VRMs and EVRDs • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules Environmental Data • Storage temperature range (Component): -40°C to +125°C • Operating temperature range: -40°C to +125°C (ambient + self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
