Technical Data 10227

Effective September 2017

Supersedes April 2014

Product features

•

11.0 mm x 8.0 mm x 7.5 mm surface mount

package

•

Ferrite core material

•

Tight tolerance DCR for sensing circuits

•

Inductance range from 100 nH to 210 nH

•

Current range from 55 A to 100+ A

Applications

•

Storage temperature range (component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

FP1108R

High frequency, high current power inductors

Pb HALOGEN

HF

FREE

•

Multi-phase regulators

•

Voltage Regulator Modules (VRMs)

•

Desktop and server VRMs and EVRDs

•

Notebook and laptop regulators

•

Data networking and storage systems

•

Graphics cards and battery power systems

•

Point-of-Load modules

•

DCR Sensing circuits

Environmental data
