background image
Technical Data 10148
Effective June 2017
Supersedes August 2013
Product features
•
12.1x8.0x8.0mm maximum surface mount
package
•
Ferrite core material
•
Controlled DCR for sensing circuits
•
Inductance range from 150nH to 250nH
•
Current range from 44 to 85 Amps
•
Halogen free, lead free, RoHS compliant
Applications
•
Storage temperature range (component):
-40 °C to +125 °C
•
Operating temperature range: -40 °C to +125 °C
(ambient plus self-temperature rise)
•
Solder reflow temperature:
J-STD-020 (latest revision) compliant
FP1208
High frequency, high current power inductors
Pb HALOGEN
HF
FREE
•
Multi-phase regulators
•
Voltage Regulator Modules (VRMs)
•
Desktop and server VRMs and EVRDs
•
Data networking and storage systems
•
Graphics cards and battery power systems
•
Point-of-Load modules
•
DCR Sensing circuits
Environmental data
