HC8-R75-R 데이터시트(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
HC8-R75-R 데이터시트(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 4120 Effective October 2015 Supersedes March 2007 Product description • Surface mount inductors, 4.0mm height, designed for higher speed switch mode applica- tions requiring low voltage and high current • Design utilizes high temperature powder iron material with a non-organic binder to eliminate thermal aging • Inductance Range from 0.175 uH to 47.3 uH • Current Range from 2.2 to 76 Amps • Frequency Range 1kHz to 500kHz Applications • Multi-phase regulators • Voltage Regulator Modules (VRMs) • Distributed power systems DC-DC converters • Desktop and server VRMs and EVRDs • Point-of-Load (POL) modules • Field Programmable Gate Array (FPGA) DC-DC converters • Battery power systems • High current power supplies • Data networking and storage systems Environmental data • Storage temperature range (component): -40°C to +155°C • Operating temperature range: -40°C to +155°C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020D compliant HC8 High current power inductors Pb |
