MPIA4040R1-R22-R 데이터시트(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
MPIA4040R1-R22-R 데이터시트(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 13 page  Product description: • AEC-Q200 Grade 3 qualified • Handles high transient inrush current spikes • Magnetically shielded • Frequency range 20kHz to 10MHz • Inductance range from 0.09µH to 22µH • Current range from 1.1A to 32.0A • 4.7 x 4.31 footprint surface mount package in 1.2, 1.5, 1.85 or 2.0mm heights • Rugged construction • Halogen free, lead free, RoHS compliant Applications: • Body electronics - Central body control module - Vehicle access control system - Headlamps, tail lamps and interior lighting - Door control • Advanced driver assistance systems - 77GHz radar systems - Automatic parking control - Collision avoidance system - Basic and smart surround, and rear and front view camera - Adaptive Cruise Control (ACC) - Car black box system • Infotainment and cluster electronics - Active noise cancellation (ANC) - Audio subsystem: head unit and trunk amp - Digital instrument cluster - In-vehicle infotainment (IVI) and navigation - Port power/USB hub for front and rear passengers • Chassis and safety electronics - Airbag control unit Environmental data: • Storage temperature range (component): -55°C to +125°C • Operating temperature range: -55°C to +125°C (ambient plus self temperature rise) • Solder reflow temperature: J-STD-020D compliant MPIA4040 Automotive Grade High Current, High Frequency, Miniature Power Inductors Technical Data 10230 Effective August 2014 HALOGEN HF FREE Pb Discontinued, Effective September 15, 2016 or until inventory is depleted. Recommended replacement MPIA40-V1 |
