1 / 7 page  Technical Data 4430 Effective June 2015 Supersedes June 2014 HCM0503 High current power inductors Product features • High current carrying capacity • Low core losses • Magnetically shielded, low EMI • Frequency range up to 1 MHz • Inductance range from 0.2 μH to 22 μH • Current range from 1.9 A to 22 A • 5.5 mm x 5.3 mm footprint surface mount package in a 3.0 mm height • Iron powder core material • Halogen free, lead free, RoHS compliant Applications • Voltage Regulator Module (VRM) • Multi-phase regulators • Point-of-Load modules • Desktop and server VRMs and EVRDs • Base station equipment • Notebook and laptop regulators • Battery power systems • Graphics cards • Data networking and storage systems Environmental data • Storage temperature range (Component): -55 °C to +125 °C • Operating temperature range: -55 °C to +125 °C (ambient + self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant Pb HALOGEN HF FREE |
