background image
Technical Data 4368
Effective May 2017
Supersedes June 2009
Product features
•
High current carrying capacity, high permeability
•
Magnetically shielded, low EMI
•
Frequency range up to 1 MHz
•
5.3 mm x 6.1 mm footprint surface mount
package in a 4.95 mm height
•
Iron powder core material
•
Halogen free, lead free, RoHS compliant
Applications
•
Voltage Regulator Module (VRM)
•
Multi-phase regulators
•
Desktop and server VRMs and EVRDs
•
Point-of-load (POL) modules
•
Notebook regulators
•
Data networking and storage systems
•
Graphics cards
•
Battery power systems
Environmental data
•
Storage temperature range (component):
-40 °C to +125 °C
•
Operating temperature range: -40 °C to +125 °C
(ambient plus self-temperature rise)
•
Solder reflow temperature:
J-STD-020 (latest revision) compliant
HCP0605
High current power inductors
Pb HALOGEN
HF
FREE
Surface Mount Device
