3323 6mm Square Single-Turn Trimmer Potentiometers

Vatronics makes 3323P,3323S,3323U,3323W,3323S,3323V

Electrical•Characteristics

Range•of•resistance10

Ω—2MΩ•

Resistance•tolerance ±10%

Terminal•resistance 1%R•or•

≤2Ω

Contact•resistance•variation CRV

≤3%R•or•3Ω

Insulation•resistance Re

≥1GΩ

Withstand voltage 500Vdc

Limit current of moving contact 30mA

Effective electrical travel 70% of total mechanical travel

3323

Vatronics Environmental•Characteristics

Rated•power (250Vmax)0.5W•70••

Temperature•range -55•—•+125•

TCR

±100ppm/•;•±250ppm/•

Temperature•variation

-55•,30min,+125•,30min 5•cycles

∆R≤3%R,•∆(Uab/Uac)≤2%

Collision 390m/s²•4000•cycles

∆R≤2%R

Vibration 10—500HZ•0.75mm,6h

∆R≤2%R,•∆(Uab/Uac)≤3%

Climate•category

∆R≤3%R•Ré≥100MΩ Endurance•at•70•

0.5W•1000h

∆R≤3%R•CRV≤3%R

Mechanical•endurance 200•cycles

∆R≤3%R•CRV≤3%R

Vatronics

Steady•damp—heat

∆R≤3%R•Re≥100MΩ

Physical•Characteristics

Total•mechanical•travel250±10°

Starting•torque

≤35•mN.m

Mark

Resistance•code,•resistance•tolerance

(±10%• no•indication),•lot•No

Standard•package 50pcs/tube
