Everlight Electronics Co., Ltd.

http://www.everlight.com

Rev

1

Page: 1 of 10

Device No:DSE-0003945

Prepared date: 22-July-2010

Prepared by:Yang yuanyuan

Technical Data Sheet

1206 Package Chip LED (1.0mm Height)

15-21/GHC-R2S2/2T

Features

․

Package in 8mm tape on 7〞diameter reel.

․

Compatible with automatic placement equipment.

․

Compatible with infrared and vapor phase reflow

solder process.

․

Mono-color type.

․

Pb-free.

․

The product itself will remain within RoHS complaint version

Descriptions

․

The 15-21 SMD LED is much smaller than

lead frame type components, thus enable

smaller board size, higher packing density,

reduced storage space and finally smaller

equipment to be obtained.

․

Besides, lightweight makes them ideal for

miniature applications. etc.

Applications

․

Backlighting in dashboard and switch.

․

Telecommunication: indicator and backlighting in

telephone and fax.

․

Flat backlight for LCD, switch and symbol.

․

General use.

Device Selection Guide

Chip

PART No.

Material

Emitted Color

Resin Color

15-21/GHC-R2S2/2T

InGaN

Brilliant Green

Water Clear
