background image
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
1
ISCZP80
Standard Recovery Diode
FEATURES
·
High surge current capability
·
Wide current range
·
Designed and qualified for industrial and consumer level
·
Minimum Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·
Battery charges
·
Converters
·
Power supplies
·
Machine tool controls
ABSOLUTE MAXIMUM RATINGS
SYMBOL
PARAMETER
CONDITIONS
VALUE
UNIT
VRRM
Repetitive Peak Reverse Voltage
1600
V
IF(AV)
Average Forward Current
TC=110℃
50
A
IF(RMS)
RMS forward current
62
A
IFSM
Surge Forward Current
50Hz
570
A
60Hz
595
I2t
Surge Forward Current
50Hz
1600
A2s
60Hz
1450
TJ
Junction Temperature
-65~160
℃
Tstg
Storage Temperature Range
-65~160
℃
THERMAL CHARACTERISTICS
SYMBOL
PARAMETER
MAX
UNIT
Rth j-c
Thermal Resistance, Junction to Case，DC operation
0.95
℃
/W
DO-5
