Data Sheet
HMC521ALC4
Rev. 0 | Page 21 of 24
THEORY OF OPERATION
The HMC521ALC4 is a MMIC mixer in a 24-terminal, RoHS
compliant, ceramic LCC package. The device can be used as
either an image reject mixer or a single sideband upconverter.
The mixer uses two standard, double balanced mixer cells and a
90° hybrid fabricated in a GaAs, MESFET process. This device
is a much smaller alternative to a hybrid style image reject mixer
and a single sideband upconverter assembly. The HMC521ALC4
eliminates the need for wire bonding, allowing the use of
surface-mount manufacturing techniques. When used as an
image reject mixer, the HMC521ALC4 downconverts radio
frequencies between 8.5 GHz and 13.5 GHz to intermediate
frequencies between dc and 3.5 GHz. When used as single
sideband upconverter, the HMC521ALC4 upconverts
intermediate frequencies between dc and 3.5 GHz to RF
between 8.5 GHz and 13.5 GHz.
