background image
TECHNICAL DATA SHEET
ATE-R10
<FOR TOPLITE COB MODULE>
5 / 9
A/1
ATE-R10 SERIES
Revision issued in 2014.
4. RELIABILITY
The reliability of products shall be satisfied with items listed below.
4-1. TEST ITEMS AND TEST CONDITIONS
NO.
TEST ITEM
TEST CONDITIONS
RESULT
1
Continuous operation test
Ta = 25℃, IF = 180 mA × 1000 hours(with Al fin)
PASS
Ta = 80℃, T j≒120℃, IF =180 mA × 1000
hours(with Al fin)
2
Low temperature storage
Ta =-40℃×1000 hours
PASS
3
High temperature storage
Ta =100℃×1000 hours
PASS
4
Moisture resistance
Ta =60℃, 90%RH for 1000 hours
PASS
5
Thermal shock
Ta =-40℃×30minutes～100℃×30minutes, 100
cycle
PASS
4-2. FAILURE CRITERIA
NO.
PARAMETER
SYMBOL
FAILURE CRITERIA
1
Forward Voltage
VF
VF ＞ Initial value × 1.1
2
Luminous Flux
Φ
Ф ＜ Initial value × 0.7
