STDP8028

Feature attributes

Doc ID 15729 Rev 1

5/8

–

Advanced Color Management with overlapping regions allows for flexible flesh-

tone compensation, blue stretch, color regions detection, and other image

enhancements

–

Advanced Contrast Control delivers smoother, more realistic gradients and

ensures that full dynamic range is used in video content

–

Patented QuickMatch technology produces uniform color responses for different

panels using flexible and programmable techniques

–

Integrated noise filter to eliminate contrast noise

●

Faroudja DCDi Cinema format conversion

–

Low angle de-interlacing processing

–

Per pixel Motion Adaptive De-interlacing (MADi) up to 1080i format

–

Format conversion up to 1080p resolutions

–

Adaptive 3D/TNR noise reduction

●

Picture-in-Picture (PIP)

–

Programmable PIP channel horizontal and vertical filter coefficients

–

Flexible PIP, PBP, and POP support capability (video, graphics)

–

DCDi Edge® processing for second channel window

●

Faroudja TrueLife video enhancer

–

High performance programmable sharpening filters with noise coring

–

Programmable main channel horizontal and vertical filter coefficients

–

Non-linear chroma and luma enhancement

●

DDR2 memory controller

–

DDR2 memory I/F support

–

Supports 16/32-bit memory I/F 1x16, 2x16, 1x32, 2x32

●

On-chip microprocessor and OSD controller

–

Integrated x186-based microprocessor with rich function library

–

General Purpose Inputs/Outputs (GPIOs) available for managing system devices

(keypad, backlight, NVRAM, etc.)

–

2-wire serial master bus interface for external device control

–

Integrated I/R decoder and 4-channel low bandwidth ADC

–

Advanced bit-mapped OSD controller

●

Output formats

–

Dual-channel/single-channel 18/24/30-bit LVDS transmitters for direct connection

to LCD modules (applicable to STDP8028 only)

–

Single-channel 24/30-bit TTL output

–

Adaptive Contrast Ratio (ACR) control for automatic, intelligent backlight

adjustments
