2 / 2 page
Tel: 800- 284-7007
www.rfswitches.com
email: switches@teledyne.com
01/2004
Specifications subject to change without notice.
9
Analog
TTL
Indicators
Series
Connectors
Actuator Voltage
Part Numbering System for CCR-33 (Failsafe)
CCR-33 S 1 O - N
Options
Actuator Type
Connector
S: SMA Female #
Actuator Voltage
1: 28Vdc Failsafe #
2: 15Vdc Failsafe #
3: 12Vdc Failsafe #
Actuator Type
O: No Indicator Contacts #
C: Indicator Contacts #
Options
T: TTL Drivers with Diodes
N: Narrow Body #
R: Positive + Common
Optional Narrow Width Body
H = 1.30 MAX. STD MODEL
H = 1.80 MAX. TTL MODEL
Standard Width Body
H = 1.30 MAX. STD MODEL
H = 1.80 MAX. TTL MODEL
For other options contact Factory
#: Stock item subject to prior sale
Commercial
CCR-33
Miniature DC-18GHz SPDT Switch
Failsafe
