Data Sheet

AS02504PR-N50-R

Introducing the N50 Mini Speaker Series from PUI Audio. High-grade

neodymium magnetic motors are employed in each N50 Series speaker to create

the highest output possible, in the smallest form factor.

The 25mm diameter AS02504PR-N50-R features a paper cone for warm,

natural sound when reproducing music or voice. A rubber surround provides

excellent damping while remaining resilient over time. 25mm long 30AWG lead

wires offer quick installation.

Features:

•

Paper cone and rubber surround

•

High 79 dB output at 1W/50cm

•

N50 neodymium motor

•

Only 7.5mm thick

•

1.5mm of excursion

Specifications

Parameters

Values

Units

Rated Input Power

2

Watts

Max Input Power

2.5

Watts

Impedance

4 ± 15%

Ohms

Sensitivity (SPL @ 1W/50cm)

(800, 1000, 1200, and 1500 Hz)

79 ± 3

dBA

Distortion (Max @ 1W, 1 kHz)

<5%

Resonant Frequency

280 ± 20%

Hz

Frequency Range

250 ~ 20,000

Hz

Housing Material

ABS

Magnet Material

NdFeB

Weight

6.7

Grams
