Data Sheet

AS03204MS-3-R

PUI Audio’s AS03204MS-3-R packs a punch despite its 32 x 32 x 16.5mm size. A

3W nominal, 4W max power handling and great sensitivity combine to make for

a small speaker that can output as much as 85 dB of sound at one meter!

The flat 200 Hz to 20,000 Hz frequency response covers over 90% of the audio

band, and high–end design—rubber surround and non-resonant frame—makes

for a speaker that truly delivers high fidelity performance. Great for critical

listening applications!

Features:

•

IP67 rated speaker face

•

High 83 dB output at 1W/50cm

•

Neodymium motor

•

Only 16.5 mm thick

•

1.5mm of excursion

Specifications

Parameters

Values

Units

Rated Input Power

3

Watts

Max Input Power

4

Watts

Impedance

4 ± 15%

Ohms

Sensitivity (SPL @ 1W/50cm)

(600, 800, 1000, and 1200 Hz)

83 ± 3

dBA

Distortion (Max @ 1W, 1 kHz)

<5%

-

Resonant Frequency

200 ± 20%

Hz

Frequency Range

200 ~ 20,000

Hz

Housing Material

ABS

-

Magnet Material

NdFeB

-

Weight

16.6

Grams

Environmental Protection Rating

IP67

-
