background image
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon NPN Power Transistor
ISCN109N
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX UNIT
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC= 30mA ; IB= 0
400
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= 10A; IB= 2A
0.5
V
VBE(sat)
Base-Emitter Saturation Voltage
IC= 10A; IB= 2A
1.3
V
ICBO
Collector Cutoff Current
VCB= 500V ; IE= 0
0.1
mA
IEBO
Emitter Cutoff Current
VEB= 10V; IC= 0
0.1
mA
hFE
DC Current Gain
IC= 10A ; VCE= 4V
10
30
COB
Output Capacitance
IE= 0 ; VCB= 10V; ftest=1.0MHz
250
pF
fT
Current-Gain—Bandwidth Product
IE= 1A ; VCE= 12V
13
MHz
