2016. 4. 23
3/4
Revision No : 0
FDR1020E
SOD-523 Package Outline Dimensions
SOD-523 Suggested Pad Layout
A
0.510
0.770
0.020
0.031
A1
0.500
0.700
0.020
0.028
b
0.250
0.350
0.010
0.014
c
0.080
0.150
0.003
0.006
D
0.750
0.850
0.030
0.033
E
1.100
1.300
0.043
0.051
E1
1.500
1.700
0.059
0.067
E2
L
0.010
0.070
0.001
0.003
° REF
7° REF
0.200 REF
0.008 REF
