Product data sheet

Characteristics

QO2125VH

QO mini breaker, 125 A, 2 pole, 120/240 V, 22

kA, plug in

Product availability : Stock - Normally stocked in distribution facility

Price** : 1,034.00 USD

Main

Product

Miniature circuit-breaker

Range

QO

Current Rating

125 A

Voltage Rating

120/240 V AC

120 V AC

Mounting Type

Plug-in

Number of Poles

2P

Circuit Breaker Type

Standard

Ratings

HACR rated

Electrical Connection

Box lugs

Complementary

Inturrupt Rating

22 kA 120/240 V AC 50/60 Hz

22 kA 120 V AC 50/60 Hz

Number of Panel Spaces

2

Wire Size

AWG 4...AWG 2/0 copper or aluminium

Tightening torque

40.71 lbf.in (4.6 N.m)

Height

88.90 mm (3.5 in)

Depth

73.91 mm (2.91 in)

Width

38.10 mm (1.5 in)

Environment

Certifications

UL listed

CSA

Ambient Rating

104 °F (40 °C)

Nov 25, 2019

1
