NX8564/8565/8566LE SERIES

Remark The graphs indicate nominal characteristics.

Life Support Applications

These NEC products are not intended for use in life support devices, appliances, or systems where the malfunction of these products can reasonably

be expected to result in personal injury. The customers of CEL using or selling these products for use in such applications do so at their own risk and

agree to fully indemnify CEL for all damages resulting from such improper use or sale.

A Business Partner of NEC Compound Semiconductor Devices, Ltd.

08/24/2004

EDFA

120 km

2.5 Gb/s

EDFA

600 km STANDARD FIBER TRANSMISSION EXAMPLE (NX8565LE Series)

Test Setup

-40

-38

-36

-34

-32

10-6

10-7

10-8

10-9

10-10

10-11

10-12

ERROR RATE CHARACTERISTICS

Received Power (dBm)

-42

10-5

10-4

10-13

back to back

after 600 km

EYE DIAGRAM

-30

-28

Back to Back (100 ps/div.)

After 600 km (100 ps/div.)

2.48832 Gb/s,

NRZ 2 VP-P,

PRBS 223-1,

Iop = 70 mA,

TC = 25ºC,

Vcenter = -1.2 V,

Vmod = 2.0 V
