background image
FUZETEC TECHNOLOGY CO., LTD.
NO.
PQ18-01ER
Product Specification and Approval Sheet Version A9
Page
3/5
NOTE : Specification subject to change without notice.
2016/7/22
5.Thermal Derating Curve
0%
50%
100%
150%
200%
-40
-20
0
20
40
60
80
Ambient Temperature (℃)
FSMD1206 Series
6.Typical Time-To-Trip at 23℃
Z= FSMD005-1206-R
A= FSMD010-1206-R
B= FSMD012-1206-R
C= FSMD016-1206-R
D= FSMD020-1206-R
E= FSMD025-1206-R /
025-24-1206-R
F= FSMD035-1206-R /
035-30-1206R
G= FSMD050-1206-R /
050-24-1206R
H= FSMD075-1206R /
075-16-1206R
I= FSMD100-1206R
J= FSMD110-1206R /
110-16-1206R
K= FSMD150-1206R
L= FSMD200-1206R
0.01
0.1
1
10
100
0.1
1
10
100
Fault current (A)
A B C D E F
G
H I
J K L
Z
