TAI-TECH

P3

4. Specification

Part Number

Inductance

L0 (uH)

@ 0 A

Tolerance

Rated current

DCR

(mΩ)

@25℃

Tempetature

current

I rms (A)

Saturation

current

I sat (A)

K

L

M

Y

typ

max

typ

max

HPC6020NF-R80

0.80

/

/

±20%

±30%

5.5

5.0

7.5

7.0

16

HPC6020NF-1R0

1.00

/

/

±20%

±30%

4.5

4.0

6.2

6.7

19

HPC6020NF-1R5

1.50

/

/

±20%

±30%

3.8

3.3

5.5

5.0

22.5

HPC6020NF-2R0

2.00

/

/

±20%

±30%

3.65

3.3

5.3

4.9

25

HPC6020NF-2R2

2.20

/

/

±20%

±30%

3.5

3.2

5.0

4.6

29

HPC6020NF-3R3

3.30

/

/

±20%

±30%

3.3

3.0

4.0

3.6

35

HPC6020NF-4R7

4.70

/

±15%

±20%

±30%

2.8

2.5

3.0

2.7

54

HPC6020NF-5R6

5.60

/

±15%

±20%

±30%

2.6

2.3

2.7

2.4

59

HPC6020NF-6R8

6.80

/

±15%

±20%

±30%

2.5

2.2

2.6

2.3

78

HPC6020NF-8R2

8.20

/

±15%

±20%

±30%

2.3

2.0

2.4

2.1

103

HPC6020NF-100

10.0

±10%

±15%

±20%

±30%

2.1

1.9

2.1

1.9

106

HPC6020NF-150

15.0

±10%

±15%

±20%

±30%

1.6

1.4

1.5

1.3

138

HPC6020NF-220

22.0

±10%

±15%

±20%

±30%

1.4

1.1

1.3

1.1

204

HPC6020NF-330

33.0

±10%

±15%

±20%

±30%

1.3

1.1

1.2

1.0

340

Note:

2. Testing Instrument : HP4284A,CH11025,CH3302,CH1320 ,CH1320S LCR METER / Rdc:CH502BC MICRO OHMMETER.

3. Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40℃.

4. Saturation Current (Isat) will cause L0

to drop approximately 30%.

5. The part temperature (ambient + temp rise) should not exceed 125℃under worst case operating conditions.Circuit design,component,PCB trace size and

thickness,airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.

6. Special inquiries besides the above common used types can be met on your requirement.
