TAI-TECH

P3

4. Specification

Part Number

Inductance

L0 (uH)

@ 0 A

Tolerance

Rated current

DCR

(mΩ) @25℃

±20%

Tempetature

current

I rms (A)

Saturation

current

I sat (A)

K

L

M

Y

HPC5040NF-R47

0.47

/

/

±20%

±30%

9.0

12.0

6.5

HPC5040NF-R60

0.60

/

/

±20%

±30%

8.00

11.0

8

HPC5040NF-1R0

1.00

/

/

±20%

±30%

5.00

7.50

12

HPC5040NF-1R5

1.50

/

/

±20%

±30%

4.50

6.50

15

HPC5040NF-1R8

1.80

/

/

±20%

±30%

4.20

6.10

18

HPC5040NF-2R2

2.20

/

/

±20%

±30%

3.80

5.70

21

HPC5040NF-3R3

3.30

/

/

±20%

±30%

3.50

4.40

24

HPC5040NF-4R7

4.70

/

/

±20%

±30%

3.20

3.90

32

HPC5040NF-6R8

6.80

/

/

±20%

±30%

2.50

3.30

43

HPC5040NF-8R2

8.20

/

/

±20%

±30%

2.35

2.90

50

HPC5040NF-100

10.0

/

/

±20%

±30%

2.20

2.52

56

HPC5040NF-150

15.0

/

±15%

±20%

±30%

1.80

2.00

80

HPC5040NF-220

22.0

/

±15%

±20%

±30%

1.50

1.62

123

HPC5040NF-270

27.0

/

±15%

±20%

±30%

1.30

1.40

160

HPC5040NF-330

33.0

/

±15%

±20%

±30%

1.20

1.30

180

HPC5040NF-470

47.0

±10%

±15%

±20%

±30%

1.00

1.10

270

HPC5040NF-680

68.0

±10%

±15%

±20%

±30%

0.80

0.90

400

HPC5040NF-820

82.0

±10%

±15%

±20%

±30%

0.75

0.78

490

HPC5040NF-101

100

±10%

±15%

±20%

±30%

0.72

0.75

560

HPC5040NF-221

220

±10%

±15%

±20%

±30%

0.55

0.62

1500

Note:

2. Testing Instrument : HP4284A,CH11025,CH3302,CH1320 ,CH1320S LCR METER / Rdc:CH502BC MICRO OHMMETER.

3. Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40℃.

4. Saturation Current (Isat) will cause L0 to drop approximately 30%.

5. The part temperature (ambient + temp rise) should not exceed 125℃under worst case operating conditions.Circuit design,component,PCB trace size and

thickness,airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.

6. Special inquiries besides the above common used types can be met on your requirement.
