VMPI42F-R10MDA 데이터시트(PDF) 1 Page - TAI-TECH Advanced Electronics Co., Ltd. |
|
|
|||||||||||||||||||||||||||||
VMPI42F-R10MDA 데이터시트(HTML) 1 Page - TAI-TECH Advanced Electronics Co., Ltd. |
|
|
1 / 3 page  TAI-TECH www.tai-tech.com.tw P1 1. Features 2. Applications 3. Dimensions B C E F A 1R0 D H 4. Part Numbering SMD Power Inductor VMPI42F-Series Halogen-free Halogen Recommend PC Board Pattern L(mm) G(mm) H(mm) 3.4 ref 1.4 ref 3.8 ref Note: 1、The above PCB layout reference only. 2、Recommend solder paste thickness at 0.12mm and above. Series A B C D E F VMPI42F 4.1±0.2 4.1±0.2 1.9±0.2 3.4±0.3 0.88±0.2 1.6±0.25 Unit:mm 1. Soft saturation. 2. High current，low DCR，high efficiency. 3. Very low acoustic noise and very low leakage flux noise. 4. High reliability. 5. 100% Lead(Pb)-Free and RoHS compliant. 6. Operating temperature -40~+125℃(Including self - temperature rise) Note PC power system，incl. IMVP-6 DC/DC converter . VMPI 42 F - 1R0 MDA A B C D E A: Series B: Dimension BxC C: Type Material. D: Inductance 1R0=1.00uH E: Inductance Tolerance M=±20% Marking: Black.1R0 and 1901(19 YY, 01 WW,follow production date). |
