Product description

• Halogen free, lead free, RoHS compliant

• 125°C maximum total temperature

operation

• 5.74 x 5.43 footprint surface mount

package with either 1.2 or 2.0mm

heights

• Magnetically shielded, low EMI

• Rugged construction

• Inductance range from 0.33µH to 15µH

• Current range from 1.1 to 11.5 amps

Applications

• Handheld/mobile devices

• Portable media players

• MP3 Players

• Battery operated devices

• Notebook/netbook

• Tablets/smartbooks

• LCD Displays

• LED Drivers

Environmental data

• Storage temperature range (Component):

-40°C to +125°C

• Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

• Solder reflow temperature:

J-STD-020D compliant

Packaging

• Supplied in tape and reel packaging on a 13”

diameter reel

Coiltronics MPI5451 Series

High current, low profile power inductors

Technical Data 10247

Effective June 2014

Coiltronics is now

part of Eaton

Same great

products plus

even more.

The Coiltronics brand of

magnetics (formerly of

the Bussmann Division of

Cooper Industries)

is now part of

Eaton’s Electrical Group,

Electronics Division.

HALOGEN

HF

FREE

Pb

Discontinued,

Effective

February

1, 2016

or until

inventory

is depleted.

No recommended

replacement

available
