DOCUMENT : CYNP-199-029

Page : 3

REVISION

: A0

Current Sensor Resistor

Type Designation :

S C M M

3923

S

7

ー

□ □ □ □

□

(1)

(2)

(3)

(4)

(5)

(6)

P/N list :

P/N

R value

TCR

Power Rating

Tolerance

(mΩ)

(ppm/K)

(W)

1%

2%

5%

SCMM3923S7-0M20*

0.2

< ±100

7



SCMM3923S7-0M30*

0.3

< ±100

7



SCMM3923S7-0M40*

0.4

< ±75

7



SCMM3923S7-0M50*

0.5

< ±75

7



SCMM3923S7-0M70*

0.7

< ±75

7



SCMM3923S7-R001*

1.0

< ±50

7



SCMM3923S7-R002*

2.0

< ±50

7



* Note : Other values and tolerance would be available, please contact Cyntec.

Note :

(1) Series No.

(2) Size

(3) Terminal Type : S = Short terminal

(4) Power Rating : 7 = 7W

(5) Resistance value : R001 = 0.001, 0M20 = 0.0002

(6) Tolerance : F = ±1%, G = ±2%, J = ±5%
