E5CS

7

Dimensions

Note: All units are in millimeters unless otherwise indicated.

■ Controller

Note: The external dimensions are the same for both models

with and without alarms.

48

× 48

6.25

(7.75)

72.5

94.45

44.8

× 44.8

60 min.

L = (48

× N − 2.5)

Mounting side-by-side

(group mounting of N Controllers)

+1

0

45

+0.6

0

45

+0.6

0

45

+0.6

0

L

Note: Use the P2CF-08 and P3G-08 Sockets for models without alarms, and use the P2CF-11 and P3GA-11 Sockets for models with alarms.

6

5

4

3

2

1 11

10

9

8

7

5

4

3

2

1

8

7

6

E5CS-U

E5CS-U + Adapter for Flush Mounting (Enclosed) + Back Connecting Socket (Order Separately)

(Without Alarms)

Terminal Arrangement

(Bottom View)

Models without

alarms

E5CS-U + Adapter for Flush Mounting (Enclosed) + Back Connecting Socket (Order Separately)

(With Alarms)

Models with

alarms

Tightening screws

48

100

7

Adapter for

flush mounting

P3GA-11

Back Connecting Socket

Panel

Y92F-30 Adapter for flush mounting

58

Tightening screws

48

95

7

Adapter for

flush mounting

P3G-08

Back Connecting Socket

Panel

Y92F-30 Adapter for flush mounting

58

Panel Cutout Dimensions
