IS25LP032D-RBLA3 데이터시트(PDF) 25 Page - Integrated Silicon Solution, Inc |
|
|
|||||||||||||||||||||||||||||
IS25LP032D-RBLA3 데이터시트(HTML) 25 Page - Integrated Silicon Solution, Inc |
|
25 / 118 page ![]() IS25LP032D IS25WP032D Integrated Silicon Solution, Inc.- www.issi.com 25 Rev. A12 08/04/2020 6.3 READ REGISTER AND EXTENDED REGISTER Read Register format and Bit definitions are described below. Read Register and Extended Read Register consist of a pair of rewritable non-volatile register and volatile register, respectively. During power up sequence, volatile register will be loaded with the value of non-volatile value. 6.3.1 READ REGISTER Table 6.7 and Table 6.8 define all bits that control features in SPI/QPI modes. HOLD#/RESET# pin selection (P7) bit is used to select HOLD# pin or RESET# pin in SPI mode when QE=“0” for the device with HOLD#/RESET#. When QE=1 or in QPI mode, P7 bit setting will be ignored since the pin becomes IO3. For 16-pin SOIC or 24-ball TFBGA with dedicated RESET# device (Dedicated RESET# Disable bit in Functional Register is “0”), HOLD# will be selected regardless of P7 bit setting when QE=“0” in SPI mode. The Dummy Cycle bits (P6, P5, P4, P3) define how many dummy cycles are used during various READ modes. The wrap selection bits (P2, P1, P0) define burst length with an enable bit. The SET READ PARAMETERS Operations (SRPNV: 65h, SRPV: C0h or 63h) are used to set all the Read Register bits, and can thereby define HOLD#/RESET# pin selection, dummy cycles, and burst length with wrap around. SRPNV is used to set the non-volatile register and SRPV is used to set the volatile register. Table 6.7 Read Register Parameter Bit Table P7 P6 P5 P4 P3 P2 P1 P0 HOLD#/ RESET# Dummy Cycles Dummy Cycles Dummy Cycles Dummy Cycles Wrap Enable Burst Length Burst Length Default 0 0 0 0 0 0 0 0 Table 6.8 Read Register Bit Definition Bit Name Definition Read- /Write Type P0 Burst Length Burst Length R/W Non-Volatile and Volatile P1 Burst Length Burst Length R/W Non-Volatile and Volatile P2 Burst Length Set Enable Burst Length Set Enable Bit: "0" indicates disable (default) "1" indicates enable R/W Non-Volatile and Volatile P3 Dummy Cycles Number of Dummy Cycles: Bits1 to Bit4 can be toggled to select the number of dummy cycles (1 to 15 cycles) R/W Non-Volatile and Volatile P4 Dummy Cycles R/W Non-Volatile and Volatile P5 Dummy Cycles R/W Non-Volatile and Volatile P6 Dummy Cycles R/W Non-Volatile and Volatile P7 HOLD#/ RESET# HOLD#/RESET# pin selection Bit: "0" indicates the HOLD# pin is selected (default) "1" indicates the RESET# pin is selected R/W Non-Volatile and Volatile Table 6.9 Burst Length Data P1 P0 8 bytes 0 0 16 bytes 0 1 32 bytes 1 0 64 bytes 1 1 |
|
