SST-90-R Product Datasheet

Mechanical Dimensions – SST-90 Over-Molded

For detailed drawing please refer to DWG-002519 document

10

PDS-002760 Rev 01

© 2015 Luminus Devices, Inc. - All Rights Reserved

10.00+.15

.00

11.00+.15

.00

3.0

DIE EMITTING

AREA

3.0

DIE EMITTING

AREA

E

E

S 8.00

4.42

TOP OF DIE EMITTING

AREA TO TOP OF

OVERMOLDED LENS

5.32±.13

SECTION E-E

5.1 7.1

9.9

1.4

3X 9.0

NOTCH INDICATES

ANODE (+)

9.9

1.4

3X 9.0

5.1

7.1

RECOMMENDED

SOLDER PAD LAYOUT

DIMENSIONS IN MILLIMETERS

Note: Luminus currently ships both an overmolded and a glass lens-based version of the SST-90 package that are functionally compatible
