 15 / 26 page
background image
Figure 10. Embossed carrier tape for VFQFPN 5 × 5 mm
T
B0
K0
D
D1
Y
P2
P0
Y
P
A0
E
W
F
Section Y - Y
User direction of feed
1.
Drawing is not to scale.
Figure 11. Chip orientation in the embossed carrier tape for VFQFPN 5 × 5 mm
User direction of feed
Table 7. Carrier tape dimensions for VFQFPN 5 × 5 mm
Package
A0
B0
K0
D1 Min.
P
P2
D
P0
E
F
W
T Max.
Unit
VFQFPN 5×5 5.25 ±0.1 5.25 ±0.1 1.1 ±0.1 1.5
8 ±0.1 2 ±0.1 1.55 ±0.05 4 ±0.1 1.75 ±0.1 5.5 ±0.1 12 ±0.3 0.3 ±0.05 mm
ST33TPHF2ESPI
Delivery packing
DB2716 - Rev 4
page 15/26
