Silicom’s Quad Port Copper Gigabit Ethernet ExpressModule Bypass server adapters are the ideal solution for implementing

multiple network segments, mission-critical high-powered networking applications and environments within high performance

servers.

Key Features

Bypass:



Bypass / Disconnect Ethernet ports on Power Fail, System Hangs or Software Application Hangs



Software programmable Bypass, Disconnect or Normal Mode



On Board Watch Dog Timer (WDT) Controller



Software programmable time out interval



Software Programmable WDT Enable / Disable counter



Software programmable Bypass Capability Enable / Disable



Software Programmable Disconnect Capability Enable / Disab



Software Programmable mode (Bypass, Normal or Disconnect mode) at Power up



Software Programmable mode (Bypass, Normal mode) at Power off



Independent Bypass operation in every two ports

Copper Gigabit Ethernet 1000Base-T:



Independently copper Gigabit Ethernet channels support four Gigabit Ethernet (1000Base-T), Fast Ethernet (100Base-Tx) and

Ethernet (10Base-T).



Triple speed 1000Mbps (1000Base-T), 100 Mbps (100Base-Tx) and 10 Mbps (100Base-T) operation



Nway auto negotiation automatic sensing and switching between 1Gbps full duplex and 100 / 10 Mbps operations Simplex or

Full Duplex



RJ-45 female connectors

Performance Features:



8 Transmit and Receive queues per port



Up to 8 queues of Receive Side Scaling (RSS) minimize CPU utilization across multiple processor systems



Support for 8 pools (single queue) of virtual machine Device Queues (VMDq) per port



Support Direct Cache Access (DCA)



Support Intel I/O Acceleration Technology v3.0.



TSO interleaving for reduced latency



Minimized device I/O interrupts using MSI and MSI-X



UDP, TCP and IP checksum offload



UDP and TCP transmit segmentation offload (TSO)
