TPC150

Specifications

15" Heavy Industrial Touch Panel PC

PROCESSOR SYSTEM

•Processors:

- Supports up to 65W TDP

•IntelH61Expresschipset

MEMORY

•TwoDDR31333/1600MHzSODIMMsockets(3rdgenerationprocessors)

TwoDDR31066/1333MHzSODIMMsockets(2ndgenerationprocessors)

•Supportsupto16GBsystemmemory

LCD and TOUCH SCREEN

•15”1024x768TFTLCDpanelwithtouchscreen

•Supports5-wireResistiveTouch

•50,000MTBFLEDbacklight

•Brightness(cd/m²):250

GRAPHICS

•Displayports:HDMIandDVI-I

•HDMIandDVI-Idisplayresolutionupto1920x1200

STORAGE

•22.5"SATAdrivebays

-SATA2.0portwithdatatransferrateupto3Gb/s

•1opticaldrivebay*

ETHERNET

AUDIO

•RealtekALC8865.1-channelHighDefinitionAudio

•Two3Wspeakers(leftandrightsides)

COM

•1RS232/422/485COMport

•1RS232COMport

USB

•2TypeAUSB2.0/1.1portsatthefrontpanel

•4TypeAUSB2.0/1.1portsatthebottom

I/O

•Front

- 2 Type A USB 2.0/1.1 ports

- 5functionkeys:power,volume,andbrightness

- 3LEDindicators:Power,HDD,Alarm

- 1 built-in antenna

•Bottom

-1DB-9RS232/422/485COM

-1DB-9RS232COM

-1PS/2keyboard

- 1 PS/2 mouse

- 4 Type A USB 2.0/1.1

- 3audiojacks:Mic-in,Line-in,Line-out

-2RJ45LANwithLEDs

- 1 DVI-I

- 1 HDMI

- 1 power switch

EXPANSION

•1PCIex1and1PCI(X100-3PE2)

•2PCI(X100-2P1M)

•2MiniPCIe

- Supports PCIe and USB signals for Wi-Fi module

-Supportshalf/fullsizeMiniPCIecard

POWER

•Powerinputvoltage

-Standard:ATXpowertype,AC100-240V,3.5A,250W

-Option:24VDC-in3-poleterminalblock

-Availableuponrequest:12Vand30VDC-in3-poleterminalblock

COOLING SYSTEM

•Smartfansystemcontrolsuitableforquietenvironments

ENVIRONMENT

•Temperature

•RelativeHumidity

•Corrosion

sprayorwaiver

VIBRATION

•Operating:1G,5~500Hz

•Non-operating:1.5G,5~25Hz

•IEC68-2-64compliant

SHOCK

•Operating:3Gpeakacceleration(11msec.duration)

•Non-operating:10Gpeakacceleration(11msec.duration)

•IEC68-2-27compliant

FRONT PANEL PROTECTION

•IP65(DustTight;WaterProofprotection)

CONSTRUCTION

•Aluminumfrontbezel

•Rearpanel:sheetmetal

MOUNTING

•VESAmount:75x75and100x100

•Wallmountbracket*

•Panelmount:mountingclamp*

DIMENSIONS

•410mmx320mmx106mm(WxHxD)

WEIGHT

•7.8kg

OS SUPPORT

•WindowsXP,WES2009,POSReady2009,Windows7,WES7

•Linux(Distributionavailableuponrequest)

CERTIFICATION

•CE

•FCCClassA

•RoHS

•UL

*Optionalandisnotsupportedinstandardmodel.Pleasecontactyoursalesrepresentativeformoreinformation.
