N-CHANNEL MOSFET

4N60A

1 / 7

www.yfwdiode.com

Dongguan YFW Electronics Co, Ltd.

4A 600V N沟道增强型场效应管

主要参数：

ID

4A

VDSS

600V

RDSON-typ(@VGS=10V)

2.1Ω

性能特点：



开关速度快



低导通电阻



低反向传输电容



低栅极电荷量



100%单脉冲雪崩能量测试



提升了dv/dt能力

机械性能：



注塑成型封装



适用任何位置安装



封装材料符合UL 94V-0燃烧防火等级标准



加工焊接峰值最高温度 275°C ；时间丌大于 10s



封装形式: TO-220AB, TO-220F, TO-263, TO-252, TO-251

G.栅极 D.漏极 S.源极

产品规格分类：

产品料号

封装形式

产品印字

包装方式

YFW4N60A1

TO-220AB

4N60AT

50PCS每管

YFW4N60A2

TO-220F(0.5mm)

4N60AF

50PCS每管

YFW4N60A3

TO-263

4N60AS

50PCS每管

YFW4N60A3-R

TO-263

4N60AS

800PCS每盘

YFW4N60A4

TO-251

4N60AMJ

75PCS每管

YFW4N60A5-R

TO-252

4N60AD

2500PCS每盘
