ST7LITE3

51/167

WATCHDOG TIMER (Cont’d)

The application program must write in the CR reg-

ister at regular intervals during normal operation to

prevent an MCU reset. This downcounter is free-

running: it counts down even if the watchdog is

disabled. The value to be stored in the CR register

must be between FFh and C0h (see Table 13

.Watchdog Timing):

– The WDGA bit is set (watchdog enabled)

– The T6 bit is set to prevent generating an imme-

diate reset

– The T[5:0] bits contain the number of increments

which represents the time delay before the

watchdog produces a reset.

Following a reset, the watchdog is disabled. Once

activated it cannot be disabled, except by a reset.

The T6 bit can be used to generate a software re-

set (the WDGA bit is set and the T6 bit is cleared).

If the watchdog is activated, the HALT instruction

will generate a Reset.

Table 13.Watchdog Timing

Notes: The timing variation shown in Table 13 is

due to the unknown status of the prescaler when

writing to the CR register.

11.1.4 Hardware Watchdog Option

If Hardware Watchdog is selected by option byte,

the watchdog is always active and the WDGA bit in

the CR is not used.

Refer to the Option Byte description in section

15.1 on page 158.

11.1.4.1 Using Halt Mode with the WDG

(WDGHALT option)

If Halt mode with Watchdog is enabled by option

byte (No watchdog reset on HALT instruction), it is

recommended before executing the HALT instruc-

tion to refresh the WDG counter, to avoid an unex-

pected WDG reset immediately after waking up

the microcontroller.

fCPU = 8MHz

WDG

Counter

Code

min

[ms]

max

[ms]

C0h

FFh

127

128
