Technical data

Maximum load current

Rated surge voltage

6 kV

Pollution degree

3

Surge voltage category

III

Insulating material group

I

Connection in acc. with standard

IEC 61984

24 A

500 V

Open side panel

ja

Number of positions

15

Connection data

Conductor cross section solid min.

0.08 mm²

Conductor cross section solid max.

4 mm²

Conductor cross section stranded min.

0.08 mm²

Conductor cross section stranded max.

2.5 mm²

Conductor cross section AWG/kcmil min.

28

Conductor cross section AWG/kcmil max

12

Conductor cross section stranded, with ferrule

without plastic sleeve min.

0.14 mm²

Conductor cross section stranded, with ferrule

without plastic sleeve max.

2.5 mm²

Conductor cross section stranded, with ferrule

with plastic sleeve min.

0.14 mm²

Conductor cross section stranded, with ferrule

with plastic sleeve max.

2.5 mm²

2 conductors with same cross section, stranded,

TWIN ferrules with plastic sleeve, max.

0.5 mm²

Type of connection

Plug connection

Stripping length

10 mm

Internal cylindrical gage

A3

Certificates / Approvals

Certification

BV, CUL, DNV, GL, GOST, LR, UL
