2 / 3 page

Silicom Ltd. Connectivity Solutions

Page

Technical Specifications

Fiber Ethernet General Technical Specifications

IEEE Standard / Network

topology:

Fiber 10Gigabit Ethernet, 10GBase-LR (1310nM)

Fiber Gigabit Ethernet, 1000Base-LX (1310nM)

Fiber core:

Single-Mode fiber: 9um

Insertion loss ratio:

-70/30:

70%

– Network ports to Monitor port

30%

– Network port to network port

Insertion loss:

(Typical)

Network Port: 1.8 dB

Monitor Port: 5.8 dB

Insertion loss:

(Measure)

Fabry-Perot laser: Network Port: 1.73 dB

Monitor Port: 5.54 dB

DFB laser: Network Port: 1.57 dB

Monitor Port: 5.57dB

Order Information

P/N

Description

Notes

TAPSF-S-R

10 /1 Gigabit (SM) Fiber TAP Stand Alone Unit

9uM, Fiber core, splitter ratio 70/30

TAPSF-S-64-R

10 /1 Gigabit (SM) Fiber TAP Stand Alone Unit

9uM, Fiber core, splitter ratio 60/40

TAPSF-S-55

10 /1 Gigabit (SM) Fiber TAP Stand Alone Unit

9uM, Fiber core, splitter ratio 50/50
