EVB-KSZ9477

EVALUATION BOARD

USER’S GUIDE

 2017 Microchip Technology Inc.

DS50002594A-page 7

Preface

INTRODUCTION

This chapter contains general information that will be useful to know before using Atlan-

tis. Items discussed in this chapter include:

• Document Layout

• Conventions Used in this Guide

• The Microchip Web Site

• Development Systems Customer Change Notification Service

• Customer Support

• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the EVB-KSZ9477 as a development tool for the

Microchip KSZ9477 gigabit Ethernet switch. The manual layout is as follows:

• Chapter 1. “Overview” – Shows a brief description of the EVB-KSZ9477.

• Chapter 2. “Board Details & Configuration” – Includes details and instructions

for using the EVB-KSZ9477.

• Appendix A. “EVB-KSZ9477 Evaluation Board” – This appendix shows the

EVB-KSZ9477.

• Appendix B. “KSZ9477 Evaluation Board Schematics” – This appendix shows

the EVB-KSZ9477 schematics.

• Appendix C. “Bill of Materials (BOM)” – This appendix includes the

EVB-KSZ9477 Bill of Materials (BOM).

NOTICE TO CUSTOMERS

All documentation becomes dated, and this manual is no exception. Microchip tools and

documentation are constantly evolving to meet customer needs, so some actual dialogs

and/or tool descriptions may differ from those in this document. Please refer to our web site

(www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each

page, in front of the page number. The numbering convention for the DS number is

“DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the

document.

For the most up-to-date information on development tools, see the MPLAB® IDE online help.

Select the Help menu, and then Topics to open a list of available online help files.
