background image
ADL8104
Data Sheet
Rev. 0 | Page 4 of 23
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
OUTPUT
OP1dB
15.5
18
dBm
PSAT
19
dBm
OIP3
32
dBm
Measurement taken at POUT per tone = 5 dBm
OIP2
52
dBm
Measurement taken at POUT per tone = 5 dBm
PAE
12
%
Measured at PSAT
DC SPECIFICATIONS
Table 4.
Parameter
Min
Typ
Max
Unit
SUPPLY CURRENT
IDQ
150
mA
Drain Current (IDD)
144
mA
RBIAS Current (IRBIAS)
6
mA
SUPPLY VOLTAGE
VDD
3
5
5.5
V
